Insulated fire hose designed especially for professional and volunteer fire brigades, both for sport and action purposes.
It can be used at temperatures from -30°C to +70°C. It is marked by three colour strips: blue-red-blue. The outside colour of the polyester fibre is luminescent yellow; the inside smooth-rubber liner is black. With its luminescent colour, the hose is well visible even at low visibility. The design of the hose results in a minimum pressure loss in water transport. The hose is certified to ČSN 80 8711.
| Trade name of the hose | PH – ACTION C52 Fire Gold |
PH – ACTION B75 Fire Gold |
|---|---|---|
| Inner diameter (mm) | 52 | 75 |
| Minimum burst pressure (MPa) | 4.9 | 4.9 |
| Test pressure (MPa) | 2.4 | 2.4 |
| Working pressure (MPa) | 1.6 | 1.6 |
| Weight without coupling (g/m) | 250 | 390 |
| Weight with couplings (kg/20m) | 5,6 | 8,8 |
| Available lengths (m) | max. 50 | max. 50 |
Ordering specifications
| Trade name | Comes with | Catalogue No. |
|---|---|---|
| PH – ACTION C52 Fire Gold | with Al coupling | hvv 091 |
| PH – ACTION C52 Fire Gold | without coupling | hvv 090 |
| PH – ACTION B75 Fire Gold | with Al coupling | hvv 093 |
| PH – ACTION B75 Fire Gold | without coupling | hvv 092 |
